Wall hood with headroom-design MIRAN
MIRAN90S1
MIRAN75S1
MIRAN60S1
Wall hood with headroom-design, hood body and shaft in
pureBLACK, glass shade safety glass black, 90/75/60 cm
Features
- Touch control operation
- White LED display
- 3 normal levels
- LED lighting
Convenience functions
- Automatic run-on function
- Grease filter cleaning indicator
- Metal grease filter dishwasher-safe
- Can also be installed without shaft
* In accordance with DELEGATED REGULATION (EU) No 65/2014.
Technical details
| Design | Wall hood with headroom-design |
| Operating mode | Exhaust air/recirculating air |
Technical details MIRAN90S1
| Energy efficiency class | B |
| Annual energy consumption | 60,4 kWh |
| Fan-Efficiency | B |
| Lighting-Efficiency | A |
| Grease filter Efficiency | B |
| Sound power min. normal level (db(A) re 1 pW) | 45 dB |
| Sound power max. normal level (db(A) re 1 pW) | 65 dB |
| Extraction rate to EN 61591 | |
| Exhaust air output min. normal level | 220 m³/h |
| Exhaust air output max. normal level | 450 m³/h |
| Exhaust air power intensive level | 650 m³/h |
Technical details MIRAN75S1
| Energy efficiency class | B |
| Annual energy consumption | 60,4 kWh |
| Fan-Efficiency | B |
| Lighting-Efficiency | A |
| Grease filter Efficiency | B |
| Sound power min. normal level (db(A) re 1 pW) | 45 dB |
| Sound power max. normal level (db(A) re 1 pW) | 65 dB |
| Extraction rate to EN 61591 | |
| Exhaust air output min. normal level | 220 m³/h |
| Exhaust air output max. normal level | 450 m³/h |
| Exhaust air power intensive level | 650 m³/h |
Technical details MIRAN60S1
| Energy efficiency class | B |
| Annual energy consumption | 60,4 kWh |
| Fan-Efficiency | B |
| Lighting-Efficiency | A |
| Grease filter Efficiency | B |
| Sound power min. normal level (db(A) re 1 pW) | 45 dB |
| Sound power max. normal level (db(A) re 1 pW) | 65 dB |
| Extraction rate to EN 61591 | |
| Exhaust air output min. normal level | 220 m³/h |
| Exhaust air output max. normal level | 450 m³/h |
| Exhaust air power intensive level | 650 m³/h |
