SurfaceINDUCTION FLI680

These models offer 4 installation options:

  • Flush-mounted
  • Mounted on the worktop
  • Mounted on the worktop with
    side mouldings in stainless steel or pureBLACK
  • Placed on the worktop with
    frame in stainless steel or pureBLACK



Features

  • Multi-slider operation
  • Red LED display
  • 6 cooking zones
  • 9 power levels
  • 6-fold booster
  • 6x timer
  • Pot size recognition


Convenience functions

  • Recognises the pot, activates the cooking zone
  • Pause function
  • 3 heat retention levels (melt, keep warm, continue cooking)
  • Childproof lock
  • Bridge function left, (centre) and right
  • Grilling possible with optional grill plate left, (centre) and right
  • One slider per cooking zone
  • hoodCON ready (automatic control for ORANIER cooker hoods with hoodCON)


Safety

  • Overflow protection
  • Overheating protection
  • Residual heat indicator
  • Operating time limit


6 induction cooking zones

  • Front left 240 x 200 mm: 2.6 kW
  • rear left 240 x 200 mm: 2.0 kW
  • MAXI zone left 240 x 400 mm: 3.6 kW
  • Centre front 240 x 200 mm: 2.6 kW
  • Centre rear 240 x 200 mm: 2.0 kW
  • MAXI zone centre left 240 x 400 mm: 3.6 kW
  • Front right 240 x 200 mm: 2.6 kW
  • Rear right 240 x 200 mm: 2.0 kW
  • MAXI zone right 240 x 400 mm: 3.6 kW



Caution! Not to be installed above base units (such as dishwashers or refrigerators) and full-corner hinged cupboards.


Technical details

Width 780 mm
Height 55 mm
Depth 520 mm
Section width 750 mm
Cut depth 490 mm
Voltage 400 V
Safeguarding 16 A
Connection 9,3 kW
Connection cable length 140 cm

Downloads

FLI680 user manual DE-EN
PDF 11.92 MB
Download
FLI680_Bedienungsanleitung_A02_DE-EN.PDF
PDF 4.94 MB
Download
FLI680 drawing INT
PDF 818.39 KB
Download

Order numbers

FLI680 FLI680
