Hob extractor with FlexX induction KXI 1092
KXI 1092 exhaust air/recirculating air
This model offers 4 installation options:
- Flush-mounted
- Mounted on the worktop
- Mounted on the worktop with
side mouldings in stainless steel or pureBLACK - Placed on the worktop with
frame in stainless steel or pureBLACK
Equipment features hob:
Features
- Touch control operation
- Red LED display
- 4 cooking zones
- 9 power levels
- 4-way booster
- 4-way timer
- Pot size recognition
Convenience functions
- Timer
- Pause function
- Child lock
- Bridge function on the right
- Grilling possible with optional grill plate on the right
Safety
- Overflow protection
- Overheating protection
- Residual heat indicator
- Operating time limit
4 induction cooking zones
- front left 185 mm: 2.0 kW
- centre left 185 mm: 1.4 kW
- MAXI-Zone right 393 x 221 mm: 3.6 kW
- front right 220 x 190 mm: 1.85 kW
- centre right 220 x 190 mm: 3.0 kW
Equipment features Cooktop extractor (exhaust air/recirculating air):
Features
- Touch control operation
- Red LED display
- 3 normal settings, 1 intensive setting
Convenience functions
- Automatic run-on function
- Grease filter cleaning indicator
- Child safety lock
- Extraction flap closes flush
- Grease filter can be removed from above
- Drawer directly under the hob
- Up to full depth possible
Safety
- Capacity of the overflow tray approx. 0.5 litres
Technical details
| Width | 910 mm |
| Height | 63-210 mm |
| Depth | 520 mm |
| Section width | 890 mm |
| Cut depth | 500 mm |
| Voltage | 400 V |
| Safeguarding | 16 A |
| Connection | 7,1 kW |
| Connection cable length | 140 cm |
| Technical data exhaust air module | |
| Energy efficiency class | A |
| Annual energy consumption | 42,3 kWh |
| Fan-Efficiency | A |
| Grease filter Efficiency | A |
| Sound power min. normal level (db(A) re 1 pW) | 39 dB |
| Sound power max. normal level (db(A) re 1 pW) | 58 dB |
| Sound pressure min./max. normal level (db(A) re 20 µPa) | 28/47 dB |
| Exhaust air output min. normal level | 183 m³/h |
| Exhaust air output max. normal level | 425 m³/h |
| Exhaust air power intensive level | 627 m³/h |
| Technology | Induction hob |
Accessories for your Hob extractor with FlexX induction KXI 1092
Order numbers
| KXI 1092 exhaust air/recirculating air | 1092 53 |
